Материнская плата Biostar FX9830P,
Socket BGA FP4, uATX, GbE LAN
Описание
24
Месяц
Месяц
| Chipset | AMD Bristol Ridge |
| CPU SUPPORT | AMD® FX-9830P Processor (Quad core 3.0GHz up to 3.7GHz) |
| MEMORY | Support Dual Channel DDR4 2400/2133/1866 MHz 2 x DDR4 DIMM Memory Slot Max. Supports up to 32GB Memory Each DIMM supports non-ECC 512MB/ 1/ 2/ 4/ 8/ 16GB DDR4 module ?Please refer to www.biostar.com.tw for Memory support list |
| INTEGRATED VIDEO | AMD Radeon™ R7 Graphics Supports HDCP |
| STORAGE | 4 x SATA III Connectors (6Gb/s) 1 x M.2 (M Key) 16Gb/s Connector support PCI-E 3.0 x2 (16Gb/s) & SATA III (6Gb/s) SSD ?When PCIE-M2_1 slot is occupied, the SATA2 connector will be disabled |
| LAN | Realtek RTL8111H - 10/100/1000Mb/s Controller Support Super LAN Surge Protection |
| AUDIO CODEC | ALC887 7.1 Channels, High Definition Audio |
| USB | 4 x USB 3.2 Gen1 Ports (2 on rear I/Os and 2 via internal headers) 4 x USB 2.0 Port(2 on rear I/Os and 2 via internal headers) |
| EXPANSION SLOT | 1 x PCI-E 3.0 x16 Slot(x8) |
| REAR I/O | 1 x PS/2 Mouse 1 x PS/2 Keyboard 2 x USB 3.2 Gen1 Ports 2 x USB 2.0 Ports 1 x HDMI Port 1 x VGA Port 1 x LAN Port 3 x Audio Jacks |
| INTERNAL I/O | 1 x USB 3.2 Gen1 Header (each header supports 2 USB 3.2(Gen1)ports) 1 x USB 2.0 Header (each header supports 2 USB 2.0 ports) 4 x SATA III Connectors (6Gb/s) 1 x Front Audio Header 1 x Front Panel Header 1 x CPU Fan Connector 1 x System Fan Connector 1 x Serial Port Header 1 x TPM Header 1 x 4-Pin Power Connector 1 x 24-Pin Power Connector 1 x Clear CMOS Header |
| H/W MONITORING | CPU / System Temperature Monitoring CPU / System Fan Monitoring Smart / Manual CPU Fan Control System Voltage Monitoring |
| DIMENSION | Micro ATX Form Factor Dimension: 18.3 cm X 20 cm ( W x L ) |
| OS SUPPORT | Supports Windows 7(32/64bit) / 10(64bit) ?BIOSTAR reserves the right to add or remove support for any OS with or without notice. |
| BUNDLE SOFTWARE | BullGuard Smart Speed LAN |
| ACCESSORIES | 2 x SATA Cable 1 x I/O Shield 1 x DVD Driver 1 x Quick Guide |
| FEATURES | Supports 100% Solid capacitor Supports BIOS-Flasher |
| Caution!! The specification and pictures are subject to change without notice! | |
