Видеокарта SAPPHIRE Radeon RX 5500 XT 4GB GDDR6 PULSE

36
Месяц
GPU

Radeon™ RX 5500 Graphics
2nd Gen 7nm GPU
RDNA Architecture

Engine Clock

• Boost Clock: Up to 1845 MHz
• Game Clock: Up to 1737 MHz

Game Clock is the expected GPU clock when running typical gaming applications, set to typical TGP(Total Graphics Power). Actual individual game clock results may vary.

Stream Processors

1408

Memory Size/Bus

4GB/128 bit GDDR6

Memory Clock

14 Gbps Effective

Displays

Maximum 4 Displays

Resolution

HDMI™: 4096×2160@60Hz
DisplayPort1.4: 5120×2880@60Hz

Interface

PCI-Express 4.0

Output

• 1x HDMI
• 3x DisplayPort

BIOS Support

• UEFI

API

• Vulkan®
• OpenGL® 4.6
• OpenCL 2.0
• DirectX® 12
• Shader Model 6.4

Game Index

Extreme 1080P

Sapphire Features

• Power Design
• Free Flow
• TriXX Supported
• TriXX Boost
• Intelligent Fan Control
• Two-Ball Bearing
• Fuse Protection

AMD Features

• RDNA Architecture
• 2nd Gen 7nm GPU
• GDDR6 Memory
• Power Efficiency
• PCI Express 4.0 Support
• Video Streaming up to 8K
• Display Port 1.4 (HBR3) / DSC
• Radeon™ Software
• Radeon™ Boost
• Radeon™ Image Sharpening
• Radeon™ Anti-Lag
• AMD FidelityFx
• Async Compute
• Radeon™ Rays Audio + True Audio Next
• Radeon™ FreeSync™ 2 HDR

Cooling

• Single Fan
• Two-Ball Bearing

Form Factor

2 slot, ATX
Dimension: 177.2 x 101.5 x 38.3(mm)

Power Consumption

• 135W

OS

Linux®, Windows® 10, Windows® 7 64bit operating system required

System Requirement

• Recommended 500 Watt Power Supply (Minimum 450 Watt Power Supply).
• 1 x 8-pin Power Connector.
• PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard.
• Minimum 4GB of system memory. 8GB recommended.
